Apex Height:
Minimum 96” (2440mm). Eaves 84” (2135mm)
Door:
Single 30”x78” (760mm x 1980mm) framed, ledged and braced half glazed doors. Stainless steel butt hinges, 5-lever mortice lock
Window:
Joinery built, double glazed. Single or multiple units 36” high (915mm)
Cladding:
Tongue and groove shiplap ¾”x4” (19mm x 100mm) Tongue and groove loglap 7/8”x4” (25mm x 100mm)
Framing:
Eased edge 1½”x3” (38mm x 75mm)
Roof:
½” (11mm) OSB board
Roofing felt:
20kg green polyester mineral felt
Floor:
¾” (18mm) plyboard
Floor joists:
1½”x2” (38mm x 50mm)
Lining:
Lined with breathable membrane
Options:
Insulation and internal cladding
APEX OR PENT ROOF
Size | Tongue & Groove
Shiplap or Loglap | Torch-on
Felt | No of
Windows |
2.4m x 1.8m (8’x6’) | £1870 | £135 | 1D |
3m x 1.8m (10’x6’) | £2025 | £175 | 1D |
3m x 2.4m (10’x8′) | £2170 | £235 | 1D |
3.6m x 1.8m (12’x6′) | £2185 | £210 | 1T |
3.6m x 2.4m (12’x8′) | £2390 | £280 | 1T |
4.2m x 2.4m (14’x8’) | £2765 | £330 | 1T |
4.8m x 2.4m (16’x8’) | £3515 | £375 | 2D |
4.8m x 3.6m (16’x12’) | £3890 | £560 | 2D |
6m x 3.6m (20’x12′) | £4575 | £700 | 2D, 1T |
6m x 4.2m (20’x14′) | £5160 | £815 | 2D, 1T |
6.3m x 4.8m (21’x16′) | £5910 | £980 | 2D, 1T |
9m x 4.2m (30’x14′) | £7630 | £1225 | 1D, 2T |
9m x 4.8m (30’x16′) | £7780 | £1400 | 1D, 2T |
Heights
Apex, to the eaves 2.1m (7‘)
Pent, low side 2.1m (7′)
All offices include:
Single framed, ledged and braced glazed door with mortice lock and butt hinges.
Joinery-built windows with double glazed units
Triple life nails
All timber is pressure treated
Breathable membrane 75mm x 38mm (3”x1¼”) framework
Optional
Extra windows 1 double unit with 2 opening windows £375
1 treble with 2 opening and 1 fixed window £400
100mm x 38mm (4”x1¼”) framing add 6% to building cost
Torch on Felt £25.65 per square metre (£2.75 per square foot)
Guttering £18 per m (£6 per square foot) – One downpipe fitted £30
ALL PRICES INCLUSIVE OF V.A.T.
